Product Details
Place of Origin: China
Brand Name: Wiremac
Certification: /
Model Number: PY-Φ500mm
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD10000-20000 Unit Price
Packaging Details: Machine dimension:L2600mm*W1300mm*H1480mm
Delivery Time: 45 working days
Payment Terms: T/T
Supply Ability: 50 sets per month
Inlet Wire Dia.: |
Φ0.08mm-Φ0.45mm |
Stranded Wire Size: |
Max 2.50mm2 |
Take Up Spool Size: |
Φ500 |
Max. Speed: |
2200RPM Per Min. |
Main Motor.: |
5HP |
Inlet Wire Dia.: |
Φ0.08mm-Φ0.45mm |
Stranded Wire Size: |
Max 2.50mm2 |
Take Up Spool Size: |
Φ500 |
Max. Speed: |
2200RPM Per Min. |
Main Motor.: |
5HP |
Application
Suitable for copper wire stranding of Power cable,Lan cable,Automatic cable,Electrical wire,Date cable,Earphone cable etc.Φ500mm PLC high speed bunching machine low cost high efficient cable twisting core wire stranding equipment strander
Specification
1.Inlet wire dia:Φ0.08-Φ0.45mm
2.Bunched wire size:Max 2.5mm2
3.Lay length: 4.24-46mm(adjustable according to customer requirement)
4.Take up spool size:Φ500mm
5.Max.rotating speed:Max.2200RPM/min
6.Motor:5HP AC motor+frequency converter
7.Brake mode:Electromagnetic brake
8.Bobbin shifting:Manual hydraulic lifting
9.Traversing method:Rolling wire with ring drive units, row pitch and breadth are adjustable
10.Protection:Automatically brake/stop
1) Wire inside and outside is broken
2) The preset length is arrived
11.Touch screen method:Touch screen+ Siemens PLC+ Magnetic powder clutch, ensure constant tension from empty to full bobbin
Contact us for more machine details,pics and videos if you are interested in.
